How to monitor CPU utilization in Linux
Published on 2020-10-16, by Javed Shaikh
Monitoring CPU utilization is one of the very important tasks of a back-end system engineer. CPU utilization is nothing but the total works or tasks being processed by your central processing unit or CPU. Its always a good practice for every developer to know the common utilities to monitor cpu utilization of the system they are working.
In windows we use Task manager to check the statistical performance of CPU, memory ,disk network.. But what about Linux operating system. Lets check it out.
We will go through these utilities one by one.
- top
- htop
- nmon
- vmstat
top
top is one of the oldest command or utility to monitor system performance. It is a built in utility for any Linux operating system. It will display information like no of tasks, no of users, cpu utilization, statistical data about memory usage and list of active processes.
Just input top and enter
1shaikh@shaikhu-com:~$ top
2here is the output of the top command
1top - 11:23:33 up 3:11, 2 users, load average: 0.86, 0.69, 1.01
2Tasks: 317 total, 2 running, 315 sleeping, 0 stopped, 0 zombie
3%Cpu(s): 34.6 us, 9.5 sy, 0.0 ni, 55.0 id, 0.0 wa, 0.0 hi, 0.8 si, 0.0 st
4MiB Mem : 7814.9 total, 938.9 free, 2650.3 used, 4225.7 buff/cache
5MiB Swap: 3906.0 total, 3906.0 free, 0.0 used. 3753.6 avail Mem
6 PID USER PR NI VIRT RES SHR S %CPU %MEM TIME+ COMMAND
7 7427 shaikh 20 0 9309320 483092 306628 S 65.7 6.0 24:12.65 chrome
8 1935 shaikh 20 0 4556040 288016 108556 S 17.6 3.6 10:12.54 gnome-shell
9 1655 shaikh 20 0 843820 76204 41576 S 10.8 1.0 5:44.07 Xorg
10 2831 shaikh 20 0 1574816 502964 363492 S 8.2 6.3 9:03.78 chrome
11 1572 shaikh 9 -11 2539652 19556 15264 S 7.2 0.2 2:08.94 pulseaudio
12Now there are few quick commands available for top utility like press below keys for respective output on top command screen
- k to kill a process. It will ask for process id or pid to kill
- p to display processes based on cpu usage
- m to display list of processes based on memory usage
- q to quit
htop
htop is another realtime cpu performance monitoring tool and is almost similar to top command but with expanded screen. It is more user friendly and will give better viewing experience than top. You may need to install this utility using below command for ubuntu os
1shaikh@shaikhu-com:~$ sudo snap install htop
2Lets take a look
1shaikh@shaikhu-com:~$ htop
2Here is the output of htop
nmon
nmon is system admin tool to monitor performance of a Linux operating system. This is developed by IBM's Nigel Griffiths and the name nmon is a short hand for Nigel's Monitor. It has nice colorful screen with many different statistical views.
First lets install this utility using below command
1shaikh@shaikhu-com:~$ sudo apt-get install nmon
2lets start it, type nmon and enter
1shaikh@shaikhu-com:~$ nmon
2You will see below menu screen for nmon
1│ ------------------------------ │
2│ _ __ _ __ ___ ___ _ __ For help type H or ... │
3│ | '_ \| '_ ` _ \ / _ \| '_ \ nmon -? - hint │
4│ | | | | | | | | | (_) | | | | nmon -h - full details │
5│ |_| |_|_| |_| |_|\___/|_| |_| │
6│ To stop nmon type q to Quit │
7│ ------------------------------ │
8│ │
9│ Use these keys to toggle statistics on/off: │
10│ c = CPU l = CPU Long-term - = Faster screen updates │
11│ C = " WideView U = Utilisation + = Slower screen updates │
12│ m = Memory V = Virtual memory j = File Systems │
13│ d = Disks n = Network . = only busy disks/procs │
14│ r = Resource N = NFS h = more options │
15│ k = Kernel t = Top-processes q = Quit │
16vmstat
This command can be used to display information about system processes, memory, swap, disk and cpu usage
Lets type vmstat and enter
1shaikh@shaikhu-com:~$ vmstat
2procs -----------memory---------- ---swap-- -----io---- -system-- ------cpu-----
3 r b swpd free buff cache si so bi bo in cs us sy id wa st
4 0 0 10240 645752 313692 3789356 0 0 55 66 493 109 18 5 76 0 0
5If you want to display vmstat for every 2 seconds, use below command
1shaikh@shaikhu-com:~$ vmstat 2
2The above command will display system status every 2 seconds unless you interrupt it. Lets take another example
1shaikh@shaikhu-com:~$ vmstat 5 10
2procs -----------memory---------- ---swap-- -----io---- -system-- ------cpu-----
3 r b swpd free buff cache si so bi bo in cs us sy id wa st
4 0 0 10240 512428 315012 3869748 0 0 52 65 487 154 18 5 77 0 0
5 0 0 10240 512428 315020 3869588 0 0 0 45 396 738 2 1 98 0 0
6 0 0 10240 481684 315028 3900856 0 0 0 7 726 1153 3 1 96 0 0
7 0 0 10240 467320 315036 3914636 0 0 0 37 743 1730 6 2 92 0 0
8 1 0 10240 486756 315052 3894072 0 0 0 90 694 1586 5 2 93 0 0
9 0 0 10240 494316 315064 3887496 0 0 0 12 592 1264 3 1 95 0 0
10 0 0 10240 500900 315072 3879552 0 0 0 9 623 1461 5 1 94 0 0
11 0 0 10240 505200 315072 3874556 0 0 0 30 893 2205 8 2 90 0 0
12 0 0 10240 474204 315080 3906004 0 0 0 156 971 2396 8 3 89 0 0
13 0 0 10240 469416 315088 3910568 0 0 0 14 920 2261 8 2 89 0 0
14The above command will display system status every 5 seconds for 10 times
Conclusion
Knowing and practicing above commands can help troubleshoot any process and performance related issue.
I know there are many more utilities out there including iostat,sar,mpstat.. and what not 😊 but I have been using these four for most of the times to keep an eye on the system. Out of these, nmon and top are my favorite utility to check the system usage data and manage the processes accordingly. Let me know which utility you have been using to monitor system health.
